XRC 60-40 P Xray Baggage Scanner

XRC 60-40 P Xray Baggage Scanner

Product Details:


Price And Quantity

  • 1 Unit

Trade Information

  • All India

Product Description

XRC 60-40 P X ray Baggage Scanner

Technical Specifications :-

X-RAY Generator and Image Performance:

Steel Penetration:

38 mm guaranteed; 40 mm typical

Wire Resolution:

38AWG guaranteed; 40AWG typical

Article Separation:

Low Z, Medium Z, High Z to 0.5 Z accuracy

Generator Cool:

Oil and forced air cooling

Anode Voltage:

160kv rated, operating at 147kv

Tube Current:

0,7 mA

Direction Of X-ray:

Vertical and upwards



Intel® Core™2 Duo Processor min.


20” LED color, flicker free.


2GB RAM minimum.

Video Card:

1 GB minimum

Hard Drive:

500 GB minimum

USB Port:

6 port minimum

Operating System:



Storage Temperature:

-20 ºC to 60 ºC

Operating Temperature:

-10 ºC to 50 ºC

Relative Humidity:

5-95% condensation

Physical Properties of SecurSCAN XRC 60-40 P Control system :-

Dimensions (LxWxH):

1,430mm x 860mm x 1310mm

Approx. Weight Unpacked:

500 Kg (1102 lbs.)

Shipping Dimensions:

1630mm x 1060mm x 1550mm.

Approx. Weight Packed:

600 Kg (1323 lbs.)

Tunnel Dimensions:

610mm (W)x 422 mm (H)

Conveyor Speed:

0.20 m/sec

Conveyor Load Capacity:

165 Kg (364 lbs.) evenly distributed

Conveyor Height:

790 mm

System Power:

230 VAC +/- 10% / 60/50Hz
