High performance network
Customer optional training mode (OTP Software mode)
Optional X Autosight software for detection narcotics substances & organic substances
Optional Threat Image Projection (TIP software)
Equipped with Crisis analyzing system (black box)
CE Certificate and AERB , India approved
General specifications | |
Conveyor Speed | 0.2 m/s |
Conveyor Max Load | 100 kg-200 kg |
Resolution | < 0.10 mm Metal wire |
Penetration | 30 mm Steel |
Film Safety | ISO1600 film guarantee |
X-ray Leakage | < 100 R/h (at the surface of the machine) |
X- Ray Generator | |
Anode Voltage | 160 KV operating at 140 KV |
Cooling Duty Cycle | oil Cooling 100% |
Image System | |
X-ray Sensor | L-Shaped Photodiode Array |
Monitor: Dual 17 LCD monitor | |
Image Process Function | Color/ monochrome image, inorganic & organic stripping, edge enhancement, image recall & reverse, penetration enhancement, image saving & searching, network, notice, image light up & down |
Image Grey Level | 4096 |
Image Max Resolution | 1024 x 768 |
Image Process Capability | process 24bit image synchronization |
Zones & Zoom | 1 - 9 image regions; 2-8 Times Enlarge, full screen continuous observation |
Other features | display of date/ time, user ID-number, luggage counter, power-on self-diagnosis, network, images searching, display of operation status, system & X-ray generation timing function |
![]() |
