6 Zone Metal Detector

6 Zone Metal Detector

Product Details:


Price And Quantity

Product Description

In line with clients' variegated requirements, we bring forth a distinguished collection of 6 Zone Metal Detector. The offered detector is designed at our vendor's end using the superb quality raw material and progressive technology. Being a quality-oriented organization, we assure our clients that this detector is excellent on counts of durability and functionality. Our offered detector is used to detect ferrous & non ferrous metals. This 6 Zone Metal Detector is available in different specifications as per clients requirement.

Features of 6 Zone Metal Detector :-

  • Green/red bicolor traffic through Lights on Control Unit & Light Indicators at Control Panel
  • 10 sensitivity levels, 246 adjustable steps at each level
  • Superior Discrimination and Precise target location identification (No false alarms... very low rate..)
  • Graphic Zone Display & Display of metal density at 10-level-VU meter with green,yellow,red LEDs
  • Environment magnetic noise level detection display on LCD Screen
  • Integrated high-tech filter circuitry eliminates magnetic&electrical interference
  • Alarm counter
  • Incoming counter separately at five digits (Visible/invisible)
  • Four-digit changeable digital Pin Code
  • Automatic Failure Display
  • Reloading the factory default settings by one-touch button
  • Easy programming and monitoring with LCD display
  • Standard menu in English, German, Spanish and Turkish
  • Relay outputs for recording CCTV, controlling turnstiles, etc. on Alarms
  • Adjustable audio alarm at 10 tons/level

Six zone metal detector Technical Specifications :-

  • Weight: 52kg
  • Gross weight: 65kg
  • Operating voltage: 70Vac - 270Vac 50Hz - 60Hz
  • Power: 10W Stand By- 20W (alarm)
  • Package Dimensions (W x H x L):
  • Box 1: 560 x 260 x 2260mm
  • Box 2: 220 x 210 x 1050mm
  • Ambient temperature: -20°C to +70°

    Optional Accessories :-

    • WTMD wheeler to simplify its relocation process.
    • Infrared portable remote controller.
    • Carriage bag.
    • SCADA/SRC software for remote controlling purpose.
    • Equipped with special batteries for its 8-11 hours of constant working purpose.

    Attributes of  6 Zone Metal Detector :-

    • The provided model of metal detector is designed as per NILECJ-0601 L1-5/IP53/IEC 348/EN60950 Class1 international specifications and CE European Union Norms. It has been manufactured on the basis of ISO 9001: 2008 quality management system.
    • As part of its multi zone detection facility, this detector is capable of identifying presence of metal in 6 zones with right or left and middle or up or downward directions.
    • The special design of this product ensures its easy configurations, trouble free upgrading and convenient replacement process.
    • It is cable of calibrating in a self regulated manner as per the environmental factors.
    • It adopts very low frequency or VLF technology with human friendly features (authorized).
    • Its control unit is equipped with red or green bicolour traffic light and its light indicators are situated at its control panel.
    • This metal detection system consists of total 10 sensitivity levels and each of these levels has 246 configurable steps.
    • High differentiation capacity and error free identification of the exact location of metal are some of its key attributes. It does not send any faulty alarm.
    • Its 10 level volume meter is instrumental in exhibiting thickness of metal and graphic zone location with red, yellow and green LED lights.
    • Its LCD screen comes in handy for showing environmental magnetic noise detection related data.
    • Its non segregated filter circuit with state of the art mechanism prevents electrical and magnetic intervention.
    • Equipped with alarm counting system.
    • Consists of five digit in built or visible incoming counter.
    • Four digit digital pin code of this metal detection system can be configured as per specific requirements.
    • Its malfunction display system works in a self regulated manner.
    • Its single touch button is used to reload its standard settings.
    • The program setting and observation functions of this product can be executed with its LCD display section.
    • It shows its menu in four different languages that include German, Turkish, Spanish and English.
    • The CCTV recording function and turnstiles regulation method depend on its relay outputs by alarm.
    • The audio alarm can be adjusted at 10 tons per level.
    • As part of its optional SCADA remote data communication accessories, we offer RS232 output and modem. The data receiving and sending parameters of this communication system can be altered by using modem or direct cable over telecom lines via PC. The mechanism of its visual as well as audible alarms can be observed via PC and its operator can access data of its hard disk. Optional software program is provided with this metal detecting equipment.
    • This system is certified as being safe for expectant mothers and users of pacemakers. Moreover, it does not affect magnetic media like tape, memory sticks and proximity cards.
    • This walk through type metal detector is convenient to install. It takes only 15 minutes to fit and it is completely free from maintenance charge.
    • Notable for its dense structure, it is available in Gray colour.
    • It has been exported to above 70 countries.

    Product details


    52 kg

    Ambient temperature

    -20 degree Celsius to +70 degree Celsius

    Gross weight

    65 kg

    Operating voltage

    70Vac - 270Vac, 50Hz - 60Hz


    10W Stand By- 20W (alarm)


    560 x 260 x 2260 mm

    Alarm Mode

    Led Lights, Sound


    2 meter, 4 meter, 6 meter, 8 meter, 10 meter
