XRC 150-165 Parcel Inspection System

XRC 150-165 Parcel Inspection System
XRC 150-165 Parcel Inspection System
Product Code : 08
Product Description

XRC 150-165 Parcel Inspection System

Technical Specifications of XRC 150-165 :-

X-RAY Generator and Image Performance

Steel Penetration:

35 mm guaranteed ; 38 mm typical

Wire Resolution:

38AWG guaranteed; 40AWG typical

Article Separation:

Low Z, Medium Z, High Z 0.5 Z accuracy

Generator Cool:

Oil and forced air cooling

Anode Voltage:

170kv rated, operating at 160kv

Tube Current:

1,0 mA

Direction of X-ray:

Vertical and upwards

HIGH-penetration X-RAY GENERATOR OPTIONS

Steel Penetration:

38 mm guaranteed; 40mm typical

Wire Resolution:

40 AWG guaranteed

Anode Voltage:

200kv rated, operating at 180kv

Tube Current:

1,0 mA

COMPUTER SPECIFICATIONS

Processor:

Intel® Core™2 Duo Processor min.

Monitor:

24” LED color, flicker free

Memory:

2GB RAM minimum

Video Card:

1 GB minimum

Hard Drive:

500 GB minimum

USB Port:

6 port minimum

Operating System:

Linux

OPERATING ENVIRONMENT

Storage Temperature:

-20 ºC to 60 ºC

Operating Temperature:

-10 ºC to 50 ºC

Relative Humidity:

5-95% condensation

PHYSICAL PROPERTIES

Dimensions

Length: 3,354 mm
Height: 2,135 mm
Width: 2,885 mm

Tunnel Dimensions:

1,535mm (W)x 1,655 mm (H)

Conveyor Speed:

0.10 m/sec

Conveyor Load Capacity:

3.000 Kg evenly distributed

Approx. Weight Unpacked:

2,000 Kg

System power:

230 VAC +/- 10% / 60/50Hz

Input/Output Rollers:

1550mm, come standard with systems.
