Baggage Scanning machine

Baggage Scanning machine

Product Details:

  • Dimension (L*W*H) 1,430mm x 860mm x 1310mm Millimeter (mm)
  • Product Type Baggage Scanning machine
  • Input Power 160kv rated, operating at 147kv Volt-Ampere-Reactive (var)
  • Color White
  • Usage industrial
  • Power Supply Electric
  • Click to view more
X

Baggage Scanning machine Price And Quantity

  • 1

Baggage Scanning machine Product Specifications

  • industrial
  • White
  • 160kv rated, operating at 147kv Volt-Ampere-Reactive (var)
  • Baggage Scanning machine
  • Electric
  • 1,430mm x 860mm x 1310mm Millimeter (mm)

Baggage Scanning machine Trade Information

  • 1 Week
  • All India

Product Description

Baggage Scanning Machine is a security facility which is used to effectively check the bags carried by the passengers. It is used at various commercial places such as airport, railway station, shopping malls, metro station etc., This high performance automated system helps to reduce the work load of security personnel and long waiting queues. The machine consist of a conveyor which carries bags and pass them from through a chamber which scans the all the items inside. Baggage scanning machine is also provided with a digital display which shows the X-ray image of the goods passing through the machine. It is able to detect various different materials such as metals, food products, plastic etc., and display it on the screen with different colors.


Technical Specifications of XRC 100-100 :-

X-RAY Generator and Image Performance

Steel Penetration:

35 mm guaranteed; 38 mm typical

Wire Resolution:

38AWG guaranteed; 40AWG typical

Article Separation:

Low Z, Medium Z, High Z to 0.5 Z accuracy

Generator Cool:

Oil and forced air cooling

Anode Voltage:

160kv rated, operating at 147kv

Tube Current:

0,7 mA

Direction of X-ray:

Vertical and upwards

HIGH-penetration X-RAY GENERATOR OPTIONS

Steel Penetration:

38 mm guaranteed; 40mm typical

Wire Resolution:

40 AWG guaranteed

Voltage:

170kv rated, operating at 160kv

Tube Current:

1,0 mA

COMPUTER SPECIFICATIONS

Processor:

Intel Core 2 Duo Processor min.

Monitor:

20 LED color, flicker free

Memory:

2GB RAM minimum

Video Card:

1 GB minimum

Hard Drive:

500 GB minimum

USB Port:

6 port minimum

Operating System:

Linux

OPERATING ENVIRONMENT

Storage Temperature:

-20 C to 60 C

Operating Temperature:

-10 C to 50 C

Relative Humidity:

5-95% condensation

PHYSICAL PROPERTIES

Dimensions

Length: 3,524 mm
Height: 2,000 mm
Width: 1,380 mm

Tunnel Dimensions:

1,000mm (W)x 1,000 mm (H)

Conveyor Speed:

0.20 m/sec

Conveyor Load Capacity:

165 Kg evenly distributed

Conveyor Height:

800 mm

Approx. Weight Unpacked:

1,500 Kg

System Power:

230 VAC +/- 10% / 60/50Hz
