Known for its light weight nature, the Flat Scan - TPXi / Flat Scan 15 is easy to carry battery driven x ray based scanning device. It has been developed and designed in close association with EOD team members and employees of emergency service to fulfill the precise requirements of required works.
The system consists of :-
- Well built detector panel
- Easy to carry x ray generator
- Chargers and batteries
- Laptop imaging station
- FlatScan-TPXi wireless communication system
- FlatScan-15 wireless and wired communication facility
- Case for its carrying purpose
- High permeability level with attributes like sub millimeter brightness
- FlatScan-TPXi spacious area with sleek detector panel
- Real time image processing facility
- Available in ready to use feature and user friendly design
- It acts as image quality improving and analysis instrument
- In built ThreadSpect software with easy to comprehend mechanism
The panel of the slim detector is located at the back part of the target and its generator is situated at its front side. Its laptop imaging station is instrumental in activating its scanning function.
The 323mmx206mm image processing area of FlatScan-15 and spacious 535 x 412mm imaging area of FlatScan-TPXi have key role in scanning of ordinary bags and luggage via one time scan. It can pierce through 32mm at 160 kv and maximum 29mm thick steel at 120kV levels. The FlatScan-TPXi and FlatScan-15 are capable of producing images with sub millimeter brightness level.
Its state of the art image processing facilities includes pan, deep focus TM, zoom, 3D emboss, stitching, annotation, measurement and identification of material. The bright image capturing and processing mechanism of FlatScan-15 and FlatScan-TPXi is useful for interpretation of image immediately sans any error.
The software of FlatScan can send the image to the screen of a remote command center and can record image in JPEG file and other types of formats of file.
Standard Package :-
- FlatScan-15: 120kV x-ray generator, X-ray detector panel, batteries, laptop computer, chargers, software
- FlatScan-TPXi: 120kV x-ray generator, X-ray detector panel, software, laptop computer, transport cases, chargers, batteries and wireless communication system.
Software Features :-
- X ray source parameters with easy configuration facility (mA, kV and time)
- Inverted images, standard images, false color images
- Histogram, rotate, DeepFocus TM, zoom, pan
- On screen measurement system as optional facility
- Capacity to differentiate materials as part of optional features
- Audio visual warming signs.
- CE certification.
- Key switch and physical safety interlock system.
